Description
Illuminate your fountain or surface aerator with the powerful, elegant glow of Kasco’s W25 LED Lighting System. Featuring bright 4000K white light and 3,569 lumens per 25-watt fixture, the W25 delivers exceptional illumination and coverage with fewer fixtures, while its watertight composite housing and low-profile design blend seamlessly into your water feature. Available in 2-, 3-, and 4-fixture kits with cord lengths up to 500 feet, the W25 offers simple plug-and-play operation with no controller required and is backed by a 3-year warranty.
Available for J Series Fountains, VFX Fountains, and Surface Aerators in 2, 3 or 4 fixture kits.
Warranty period: 3 years
W25 LED Lighting for a Timeless Appeal
- 4000K white light for radiant illumination
- 2-, 3-, and 4-fixture kits available in multiple power cord lengths
- Perfect for fountains or surface aerators
- No controller needed (plug into 120V GFCI-protected outlet)
- Watertight composite fixture
- 3-year warranty
Product Notes:
- Fixtures are daisy-chained together with a single, submersible quick disconnect.
- Protective cord sleeving included on each fixture. 3 ft. of sleeving included on main power cord(s).
- Fixtures cannot be serviced in the field and individual fixtures cannot be swapped.
- W25 4-fixture kits require a 6-light kit adapter (PN 840306). See page 67.
- W25 4-fixture kits must use the 3HP and 5HP surface aerator 3-piece sectional float.
- Use the provided cable ties to attach fixture cords to the float to avoid cuts or damages to the cords.
2- Fixture Kits – Recommended for 1/2 & 3/4HP Units
| Part Number | Cord Length (ft.) | Number of Fixtures |
|---|---|---|
| LED2W25-050 | 50 ft. | 2 |
| LED2W25-100 | 100 ft. | 2 |
| LED2W25-150 | 150 ft. | 2 |
| LED2W25-200 | 200 ft. | 2 |
| LED2W25-250 | 250 ft. | 2 |
| LED2W25-300 | 300 ft. | 2 |
| LED2W25-400 | 400 ft. | 2 |
| LED2W25-500 | 500 ft. | 2 |
3- Fixture Kits – Recommended for 1/2, 3/4, 1, 2, & 3HP Units
| Part Number | Cord Length (ft.) | Number of Fixtures |
|---|---|---|
| LED3W25-050 | 50 ft. | 3 |
| LED3W25-100 | 100 ft. | 3 |
| LED3W25-150 | 150 ft. | 3 |
| LED3W25-200 | 200 ft. | 3 |
| LED3W25-250 | 250 ft. | 3 |
| LED3W25-300 | 300 ft. | 3 |
| LED3W25-400 | 400 ft. | 3 |
| LED3W25-500 | 500 ft. | 3 |
4- Fixture Kits – Recommended for 2, 3, 5, & 7.5HP Units
| Part Number | Cord Length (ft.) | Number of Fixtures |
|---|---|---|
| LED4W25-050 | 50 ft. | 4 |
| LED4W25-100 | 100 ft. | 4 |
| LED4W25-150 | 150 ft. | 4 |
| LED4W25-200 | 200 ft. | 4 |
| LED4W25-250 | 250 ft. | 4 |
| LED4W25-300 | 300 ft. | 4 |
| LED4W25-400 | 400 ft. | 4 |
| LED4W25-500 | 500 ft. | 4 |
- All kits include an additional fixture on the float with an antenna to increase signal strength.
- Fixtures are daisy chained together with a single, submersible quick disconnect.
- Protective cord sleeving included on each fixture. 3 ft. of sleeving included on main power cord.
- Fixtures cannot be serviced in the field and individual fixtures cannot be swapped.
Downloads
PDF File: Kasco WaterGlow W25 LED Lighting Manual
